5A60 Varos socket – Key aspects of the manufacturing process | Ottobock

Varos

Item #: 5A60

Added to your shopping cart

Suggested HCPCS Coding: Definitive: L5321 + L5649 + L5920 + L5950 + L5671 (+ L5673 for 6Y200 Varos Liner)

Replacement: L5701 + L5649 + L5950 + L5671 (+ L5673 for 6Y200 Varos Liner)

Preparatory: L5585 + L5649 + L5950 + L5671 (+ L5673 for 6Y200 Varos Liner)

Learn more about our Reimbursement Services

Overview

Benefits for User:

Easy user adjustability for limb volume variations (Boa Fit Dial System)
Low product weight thanks to lightweight carbon composite strut construction
High wearing comfort utilizing more flexible material than a standard socket
Secure hold in the socket (magnetic distal liner connection, good static friction properties of the specific Varos liner)
Easy donning and doffing even when seated

Benefits for CPO:

Custom made to the patient specifications with easy adjustments and modular structure
Thermoformable material for patient specific customizations
Less effort for socket fit adaptations
Easy alignment optimization utilizing a spherical distal adapter allowing for a hip flexion compensation up to 15°

Specifications

Varos sizing
	VAROS S (Small) 5A60=(L/R)-S	Varos SC (Small Conical) 5A60=(L/R)-SC	Varos M (Medium) 5A60=(L/R)-M	Varos MC (Medium Conical) 5A60=(L/R)-MC	Varos L (Large) 5A60=(L/R)-L
Proximal residual limb circumference (mm)	410 – 510	460 - 580	460- 580	520 - 650	520 - 650
Distal residual limb circumference (mm)	320 - 390	320 - 390	350 - 440	350 - 440	400 - 490
Residual limb length (mm)	200 - 320	200 - 320	200 - 320	200 - 320	200 - 320
Adjustable socket length (mm)	200 - 320	200 - 320	200 - 320	200 - 320	200 - 320
Weight limit (mm)	220 lbs (100kg)	220 lbs (100kg)	220 lbs (100kg)	220 lbs (100kg)	275 lbs (125kg)

"*Socket length of Varos is defined as distance between medial rim of socket (lowest point) to bottom of socket, measured in direction of longitudinal axis of the socket"
