Hybrid Liner, TT

Item #: 6Y100

Added to your shopping cart

Suggested HCPCS Coding: L5679

Learn more about our Reimbursement Services

Overview

Joined using a special process, the Hybrid Liner combines two liner materials and their favorable properties. The interior is made of polyurethane and protects the residual limb and bony structures thanks to its shock absorbing characteristics. At the same time, it ensures optimum pressure distribution across the entire residual limb, both for passive and active generation of the vacuum. The outside of the liner and the integrated vacuum flap are made of silicone, proven in everyday use thanks to its robustness. This is particularly important when the vacuum flap is folded over the inner socket to create an airtight seal for the system.

Try our Interactive Liner Selection Tool here: https://academy.ottobockus.com/toolbox/liners/liners

Specifications

Residual limb circumference (mm)	Size (mm)	75 mm Length Article Number	125 mm Length Article Number	175 mm Length Article Number	225 mm Length Article Number
160 - 185 mm	160 mm	6Y100=160x75	6Y100=160x125	6Y100=160x175	6Y100=160x225
180 - 205 mm	180 mm	6Y100=180x75	6Y100=180x125	6Y100=180x175	6Y100=180x225
200 - 220 mm	200 mm	6Y100=200x75	6Y100=200x125	6Y100=200x175	6Y100=200x225
210 - 230 mm	210 mm	6Y100=210x75	6Y100=210x125	6Y100=210x175	6Y100=210x225
220 - 240 mm	220 mm	6Y100=220x75	6Y100=220x125	6Y100=220x175	6Y100=220x225
236 - 260 mm	235 mm	6Y100=235x75	6Y100=235x125	6Y100=235x175	6Y100=235x225
250 - 275 mm	250 mm	6Y100=250x75	6Y100=250x125	6Y100=250x175	6Y100=250x225
265 - 290 mm	265 mm	6Y100=265x75	6Y100=265x125	6Y100=265x175	6Y100=265x225
280 - 310 mm	280 mm	6Y100=280x75	6Y100=280x125	6Y100=280x175	6Y100=280x225
305 - 330 mm	300 mm	6Y100=300x75	6Y100=300x125	6Y100=300x175	6Y100=300x225
325 - 350 mm	320 mm	6Y100=320x75	6Y100=320x125	6Y100=320x175	6Y100=320x225
345 - 370 mm	340 mm	6Y100=340x75	6Y100=340x125	6Y100=340x175	6Y100=340x225
