Single Axis Knee Joint, Brake Titan.

Item #:3R49

Available Today
Log in to order
Suggested HCPCS Coding: L5812 + L5850
Learn more at Reimbursement Services

  Try the L-Coder Calculator

The swing block is connected to the upper joint section through the swing axis and with the lower joint section through the knee axis and acts as a load-dependent brake. This together with proper knee alignment secures the stance phase. To control the swing phase, the axis friction and the spring force of the extension assist are adjustable.

Activity Level K1, K2
Maximum Body Weight 220 lbs (100 kg)
Material Titanium
Proximal Connection Pyramid Adapter
Distal Connection Pyramid Adapter
Maximum Knee Flexion Angle 150 degrees
Knee Center to Proximal Connection 40 mm
Product Weight 360 g

3R15 Stainless Stell Monocentric, 3R49 Titanium Modular Knee Joints - Instructions for Use

Instructions for Use: 647H84 (EN/DE/FR/IT/ES/PT/NL/SV/DA/PL/HU/CS/RO/HR/TR/EL/JA/ZH)

Published Date: February 13, 2017

Fabrication Order Form for Transfemoral or Knee Disarticulation

Order Form: (EN)

Published Date: May 1, 2015
