Prosthetic Med. Duty Nickel-plated Jt's

Item #: 7U25
Medium duty forged nickel plated knee joint bar
Log in to order

Overview

Forged nickel plated Joints with ball bearing, joint center placed to the posterior, concave half-round bar profile, forged nickel-plated upper and lower joint bars and the heads of both bars offset outside.

Specifications

Milled Head 26x5 mm
Upper Length from Joint Center 410 mm
Lower Length from Joint Center 150 mm
Bar Width 24 mm
Bar Thickness 3 mm (0.118 in)
Quantity Pair

Documents

Refine results

007G/U - Stainless Steel, Nickel-plated Safety Data Sheet

Safety Data Sheet

PDF Document | Published: Mar 6, 2015

007G/U - Stainless Steel Nickel-plated Safety Data Sheet

Safety Data Sheet

PDF Document | Published: Mar 22, 2018

Knee joint bars - Instructions for use

7G3, 7U2, 7U10, 7U15, 7U25, 7U27, 7U30, 7U32, 7U33, 7U42, 7U43, 7U46

Instructions for Use

PDF Document
