Overview
The 4R43 Lamination Anchor can be combined e.g. with the 4R44=L Pyramid Receiver with Threaded Connector as a length-adjustable socket connection, or with the 4R57=ST Rotation Adapter. In the latter case, the 4X46=ST Lamination Dummy has to be used for laminating. It must be ordered separately.
Use the 4X46 Lamination Dummy when laminating. It must be ordered separately.
Specifications
| Material | Stainless Steel |
|---|---|
| Maximum Body Weight | 275 lbs (125 kg) |
| Product Weight | 95 g |
Spare parts
Documents
4R111, 4R111=N, 4R111=T, 4R116, 4R116=T, 4WR95=2, 4R117, 4R117=T, 4R119=N, 4R119=NT, 4R119, 4R119=T, 4WR95=1 Four Arm Lamination Anchors, 4R41, 4R42, 4R42=1, 4R43, 4R89 Three Arm Lamination Anchors - Instructions for Use
Instructions for Use: 647G123 (EN/DE/FR/IT/ES/PT/NL/SV/DA/NO/PL/HU/CS/RO/HR/BS/TR/EL/RU/JA/ZH)
Publish date: Jul 9, 2020
PDF Document (647G123-all_INT_INT-20-2006w(3553532)_en.pdf | 2 MB)
