Dynoform

Item #: 617S70

Log in to order

Overview

Soft padding material: thermoformable at approx. 110°–130°C/230° - 266°F high resilience, pressure resistant, suitable for vacuum forming, non-shrinking, good mechanical properties, hardness approx. 33° Shore A Resistant to perspiration and saliva, meets all food legislation requirements. The material is free of AZO and PCP substances.

Specifications

Color Length Width Thickness Article Number
brown (B) 1000 mm 1000 mm 2 mm 617S70=B2
brown (B) 1000 mm 1000 mm 3 mm 617S70=B3
brown (B) 1000 mm 1000 mm 4 mm 617S70=B4
brown (B) 1000 mm 1000 mm 5 mm 617S70=B5
brown (B) 1000 mm 1000 mm 7 mm 617S70=B7
brown (B) 1000 mm 1000 mm 10 mm 617S70=B10
blue (BL) 1000 mm 1000 mm 2 mm 617S70=BL2
blue (BL) 1000 mm 1000 mm 3 mm 617S70=BL3
blue (BL) 1000 mm 1000 mm 4 mm 617S70=BL4
blue (BL) 1000 mm 1000 mm 5 mm 617S70=BL5
beige (H) 1000 mm 1000 mm 2 mm 617S70=H2
beige (H) 1000 mm 1000 mm 3 mm 617S70=H3
beige (H) 1000 mm 1000 mm 4 mm 617S70=H4
beige (H) 1000 mm 1000 mm 5 mm 617S70=H5
beige (H) 1000 mm 1000 mm 6 mm 617S70=H6
beige (H) 1000 mm 1000 mm 7 mm 617S70=H7
beige (H) 1000 mm 1000 mm 8 mm 617S70=H8
beige (H) 1000 mm 1000 mm 10 mm 617S70=H10
red (R) 1000 mm 1000 mm 2 mm 617S70=R2
red (R) 1000 mm 1000 mm 3 mm 617S70=R3
red (R) 1000 mm 1000 mm 4 mm 617S70=R4
red (R) 1000 mm 1000 mm 5 mm 617S70=R5
white (W) 1000 mm 1000 mm 2 mm 617S70=W2
white (W) 1000 mm 1000 mm 3 mm 617S70=W3
white (W) 1000 mm 1000 mm 4 mm 617S70=W4
white (W) 1000 mm 1000 mm 5 mm 617S70=W5
white (W) 1000 mm 1000 mm 7 mm 617S70=W7
white (W) 1000 mm 1000 mm 10 mm 617S70=W10
white (W) 1000 mm 1000 mm 14 mm 617S70=W14

Documents

Refine results

Information on areas of application and temperature recommendations for padding materials

Product Information: 646F295 (EN)

Publish date: Feb 1, 2014

PDF Document (646F295-GB-05-1402w.pdf | 592 KB)
