Overview
With clearances under two inches, the LP Symes Prosthetic Foot accommodates the build height requirements of Symes level amputees, while providing superior energy storage and return, and a smooth and natural rollover. The LP Symes is an ideal component for K3/4 level amputees seeking a dynamic prosthetic foot component that is flexible and comfortable, yet also durable and capable of managing the considerable force generated by long residual limbs.
The product incorporates a direct lamination cup, which keeps the distal mass as light as possible, reducing amputee energy expenditure during the gait cycle. An enhanced material tie-in groove located on the direct lamination cup has been enlarged to improve the ease of socket connection and lamination.
Features
- Carbon fiber construction is engineered to manage the high forces applied by Symes amputees, delivering flexibility and comfort in a durable design
- Remarkably lightweight – averaging 295 g
- Direct lamination cup allows for less than 2.4″ of clearance
- Rated to 365 lbs. (166 kg)
- Water-resistant
Specifications
Activity Level | K3 |
---|---|
Maximum Body Weight | 365 lbs (166 kg) |
Sizes | 22 cm - 31 cm |
Stiffness | 1, 2, 3, 4, 5, 6, 7, 8, 9 |
Heel Height | 3/8" (10 mm) |
Footshell Color | Light, Medium, Dark |
~ Min. Clearance Height (Size 26 cm) | 68 mm (2 11/16") |
Product Weight (w/ footshell) (Size 26 cm) | 20.81 oz (590 g) |
Documents
Instructions for Use - LP Symes
Instructions for Use: 647G1713 (EN)
Publish date: Mar 1, 2021
LP2 LP Symes Spec Sheet
Product Information: (EN)
Publish date: Mar 26, 2021
